Graphics Library for any EcoStuxure™ Edge Control Software

Library to use in any EcoStuxure™ software

Enhanced graphics library for EcoStuxure™ Power Monitoring Expert and other HMI

Our FREE graphics library comes with more over 850 files that improve on the default extensions provided from Schneider Electric. Save time and improve your HMI development with ready-to-use graphics.

Overview Image

Features and Benefits

Improved customer satisfaction.

Provide a more modern interface with improved usability for your customers. User Experience (UX) involves design skills and formal training, and this ready-to-use graphics package simplifies the deployment of improved screen developments.
Show more
Provide a more modern interface with improved usability for your customers. User Experience (UX) involves design skills and formal training, and this ready-to-use graphics package simplifies the deployment of improved screen developments.
Show less

Sell more to your clients by offering a better package of template screens.

Promote a greater possible range of screens (one-lines, elevations, equipment level, summary overlays) in your project tenders using this package of graphic extensions.
Promote a greater possible range of screens (one-lines, elevations, equipment level, summary overlays) in your project tenders using this package of graphic extensions.

More intuitive screen designs.

Provide a more intuitive solution for your customers by using a broader range of graphic elements in your HMI package. Providing a more consistent design concept in all interfaces will help boost adoption of your software solution.
Show more
Provide a more intuitive solution for your customers by using a broader range of graphic elements in your HMI package. Providing a more consistent design concept in all interfaces will help boost adoption of your software solution.
Show less
